Features
Low insertion loss
High return loss
LSZH cable sheath
Qualified with CE and RoHS certification
Comply with IEC criterion
Application
FTTA
Parameter
|
IL |
≤ 0.3dB (850nm) |
|
RL |
≥ 30dB (850nm) |
|
Connector |
LC (IEC 61754-20) |
|
End face |
IEC 61300 3-35 |
|
Fiber |
OM3-300 |
|
Length |
12.0m |
|
Cable OD |
5.0mm |
|
Sheath material |
LSZH |
|
Operating temp |
-40℃~85℃ |
|
Storage temp |
-40℃~85℃ |
