Features
Special bend-resistant fiber provides high bandwidth and excellent transmission performance
Simple structure, light weight and high practicability
Unique groove design, easy to strip,connect, simplify the installation and maintenance
Applications
FTTH
Technical Specification
|
Type
|
Fiber Count
|
Dimension (mm) |
Cable Weight Kg/Km
|
Tensile Strength (Long/Short Term) (N) |
Crush Resistance (Long/Short Term) (N/100mm) |
Bending Radius (Dynamic/Static) （mm） |
|
GJXFHS-1 |
1 |
7.3±0.3 |
42 |
200/600 |
2000 |
10D/20D |
|
GJXFHS-2 |
2 |
7.3±0.3 |
42 |
200/600 |
2000 |
10D/20D |
Fiber
|
Type |
G652D,G657A1,G657A2,else |
Optivcal performance
|
Fiber Type |
Single-mode |
|
|
Wavelength(nm) |
1310/1550 |
|
|
Attenuation(dB/km) |
Typical Value |
0.36/0.22 |
|
Max Value |
0.5/0.4 |
|
|
Minimum Bandwidth(MHZ.km) |
--- |
|
Environmental characteristic
|
Transport / Storage / Operating Temperature |
-20℃~+60℃ |
Standard
Comply with standard YD/T 1997.1
