Features
Low insertion loss
Alignment achieved with high precision guide pins
Various fiber and cables are available
Qualified with CE and RoHS certification
Applications
High-Speed transport system
Test device
Data Center
Specifications
|
Parameter |
Single mode |
Multi-mode |
|
Low insertion Loss |
≤0.35db |
≤0.35db |
|
Standard insertion Loss |
≤0.75db |
≤0.6db |
|
Return Loss |
≥50db |
≥20db |
|
Operation temperature |
-40℃~+80℃ |
-40℃~+80℃ |
|
Repeatability |
≤0.2db |
≤0.2db |
|
Interchangeability |
≤0.2db |
≤0.2db |
|
Endurance |
1000pull-out life; Normal insertion Value ≤0.2db |
|
|
Temperature |
75℃,relative humidity 95%≤0.3db |
|
