Features
Good mechanical and temperature performance
High strength loose tube with good hydrolysis resistant
Specially designed compact structure to prevent loose tube from shrinking
PE sheath with excellent UV resistance
Special tube filling compound ensure critical protection of fiber
APL moisture barrier
Application: underground and aerial installation
Technical specification
|
Cable Type |
Fiber Count |
Tubes |
Fillers |
Cable Weight kg/km (Ref) |
Tensile Strength (long /short term) (N) |
Crush Resistance (long /short term) (N/100mm) |
Bending Radius (Dynamic/Static) (mm) |
|
GYTA-2~6 |
2~6 |
1 |
4 |
76 |
600/1500 |
300/1000 |
10D/20D |
|
GYTA-8~12 |
8~12 |
2 |
3 |
76 |
|||
|
GYTA-14~18 |
14~18 |
3 |
2 |
76 |
|||
|
GYTA-20~24 |
20~24 |
4 |
1 |
76 |
|||
|
GYTA-26~30 |
26~30 |
5 |
0 |
76 |
|||
|
GYTA-32~36 |
32~36 |
6 |
0 |
85 |
|||
|
GYTA-38~48 |
38~48 |
4 |
1 |
90 |
|||
|
GYTA-50~60 |
50~60 |
5 |
0 |
90 |
|||
|
GYTA-62~72 |
62~72 |
6 |
0 |
113 |
|||
|
GYTA-74~84 |
74~84 |
7 |
1 |
136 |
|||
|
GYTA-86~96 |
86~96 |
8 |
0 |
136 |
|||
|
GYTA-98~10 |
98~108 |
9 |
1 |
163 |
|||
|
GYTA-110~120 |
110~120 |
10 |
0 |
163 |
|||
|
GYTA-122~132 |
122~132 |
11 |
1 |
190 |
|||
|
GYTA-134~144 |
134~144 |
12 |
0 |
190 |
|||
|
GYTA-146~216 |
146~216 |
13~18 |
5~0 |
190 |
|||
|
GYTA-288 |
288 |
24 |
0 |
239 |
Fiber
|
Fiber Type |
G652D,G657A1,G657A2,OM1,OM2,OM3,OM4 |
Transmission Performance
|
Fiber Type |
Single-mode fiber |
62.5/125(OM1) |
50/125(OM2) |
50/125(OM3) |
50/125(OM4) |
|
|
Wavelength(nm) |
1310/1550 |
1300/850 |
1300/850 |
1300/850 |
1300/850 |
|
|
Attenuation (dB/km) |
Typical Value |
0.36/0.22 |
3.0/1.0 |
3.0/1.0 |
3.0/1.0 |
3.0/1.0 |
|
Max Value |
0.5/0.4 |
3.5/1.5 |
3.5/1.5 |
3.5/1.5 |
3.5/1.5 |
|
|
Minimum Bandwidth(MHZ.km) |
--- |
≥200/500 |
≥500/500 |
≥1500/500 |
≥3500/500 |
|
Environmental Characteristics
|
Transport / Storage / Operating Temperature |
-40℃~+70℃ |
Standard
Comply with standard YD/T 901, IEC 60794-1, etc.
