Features
Compact design
Bundled fiber with connectors optional
Qualified with CE and RoHS certification
Comply with GR-1209-CORE, GR-1221-CORE, YD/T 2000.1-2014 and IEC criterion
Applications
Fiber Splice Closure
ODB
Specifications
|
Parameters |
1X2 |
1x4 |
1x8 |
1x16 |
1x32 |
1x64 |
2X2 |
2x4 |
2x8 |
2x16 |
2x32 |
2x64 |
UNIT |
|
Wavelength |
1260 ～ 1650 |
nm |
|||||||||||
|
IL ( Max) |
3.9 |
7.2 |
10.3 |
13.6 |
16.9 |
20.1 |
4.0 |
7.5 |
10.6 |
13.8 |
17.1 |
20.4 |
dB |
|
Uniformity |
0.5 |
0.7 |
0.8 |
1.0 |
1.5 |
2.0 |
0.5 |
0.7 |
0.8 |
1.0 |
1.5 |
2.0 |
dB |
|
RL (Min) |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
dB |
|
PDL (Max) |
0.15 |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
0.15 |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
dB |
|
Directivity (Min) |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
dB |
|
Fiber |
G657A or Customized |
|
|||||||||||
|
Operating Temp. |
-40~85 |
℃ |
|||||||||||
|
Storage Temp. |
-40~85 |
℃ |
|||||||||||
|
WDL |
0.5 |
0.8 |
0.8 |
1.0 |
1.5 |
2.0 |
0.5 |
0.8 |
0.8 |
1.0 |
1.5 |
2.0 |
dB |
|
TDL |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
dB |
|
Dimension |
4 x 4 x 40 |
7 x 4 x 50 |
12 x 4 x 60 |
4 x 4 x 40 |
7 x 4 x 50 |
7 x 4 x 60 |
12 x 4 x 60 |
mm |
|||||
Note:
●Parameters are taken at room temperature without connector
●Package dimensions can be customized
●RL (APC) ≥55dB
