Features
Special bend-resistant fiber provides high bandwidth and excellent transmission performance
Simple structure, light weight and high practicability
Unique groove design, easy to strip,connect, simplify the installation and maintenance
Applications
FTTH
Specifications
|
Type
|
Fiber Count
|
Dimension (mm) |
Cable Weight Kg/Km
|
Tensile Strength (Long /Short Term) (N) |
Crush Resistance (Long/Short Term) (N/100mm) |
Bending Radius (Dynamic/Static) （mm） |
|
GJYXFCH-1 |
1 |
(2.0±0.1)×(5.0±0.1) |
20 |
300/600 |
1000/2200 |
15/30 |
|
GJYXFCH-2 |
2 |
(2.0±0.1)×(5.0±0.1) |
20 |
300/600 |
1000/2200 |
15/30 |
|
GJYXFCJH-1 |
1 |
(2.0±0.1)×(5.6±0.1) |
21 |
300/600 |
1000/2200 |
15/30 |
|
GJYXFCDH -4 |
4(Ribbon) |
(2.0±0.2)×(6.0±0.2) |
22 |
300/600 |
1000/2200 |
15/30 |
Fiber
|
Type |
G652D,G657A1,G657A2,else |
Optical Performance
|
Fiber Type |
Single-mode |
|
|
Wavelength(nm) |
1310/1550 |
|
|
Attenuation(dB/km) |
Typical Value |
0.36/0.22 |
|
Max Value |
0.5/0.4 |
|
|
Minimum Bandwidth(MHZ.km) |
--- |
|
Environmental Characteristic
|
Transport / Storage / Operating Temperature |
-20℃~+60℃ |
Standard
Comply with standard YD/T 1997.1
